UniFormation GK3 PRO 16k Resin 3D Printer 385nm UV SLA Printer with Industrial Grade Quality

Uniformation GK3 Pro — 16K Resin 3D Printer with 14×19 µm XY Resolution

The Uniformation GK3 Pro is the precision-first flagship of the GK3 series — a 16K monochrome LCD resin printer engineered for creators who need the sharpest possible detail on every print. With an XY resolution of just 14×19 µm, a COB light source with Fresnel collimator lens, dual-rail dual ball screw Z-axis, and a full suite of automated workflow features, the GK3 Pro sets the standard for desktop resin printing quality.

16K Resolution — 14×19 µm Pixel Size

The GK3 Pro's 9.6" monochrome LCD delivers a native resolution of 15120×6230 pixels — a true 16K panel with an XY pixel size of just 14×19 µm. That's finer than the vast majority of desktop resin printers on the market, including larger-format machines. The result is surface texture, edge sharpness, and fine detail reproduction that rivals professional-grade equipment. The COB light source and Fresnel collimator lens work together to distribute 405nm UV light uniformly across the entire 222×130mm build plate, ensuring consistent curing from edge to edge with no soft spots or fall-off.

Dual-Rail, Dual Ball Screw Z-Axis — Industrial Stability

The GK3 Pro's all-metal chassis is built around a dual-rail, dual ball screw Z-axis that eliminates Z-wobble and layer shifting entirely. Every layer lands exactly where it should, from the first to the last, regardless of print speed. This is the same mechanical architecture found in industrial resin equipment — applied here to a desktop form factor without compromise.

Automated Workflow — Resin Feeding, Heating & Leveling

The GK3 Pro's intelligent systems handle the tedious parts of resin printing automatically. The auto resin feeding system keeps the vat topped up from a cartridge without interrupting the print. A smart heating system maintains optimal resin temperature regardless of ambient conditions — critical for consistent results across different resin types and seasonal temperature variation. Auto-leveling handles bed calibration in one step, and the quick-release build plate and anti-drip design keep post-processing clean and fast.

5-Inch Rotating Capacitive Touchscreen

The GK3 Pro features a 5-inch rotating capacitive touchscreen — one of the few desktop resin printers to offer a rotating display. Position it at the angle that works best for your workspace without moving the printer. The interface is clean, responsive, and built for fast workflow.

Specifications

GK3 Pro vs GK3 Ultra — Which One?

The GK3 Pro prioritizes resolution and detail precision with a 14×19 µm pixel size on a 222×130mm build plate. The GK3 Ultra prioritizes volume and throughput with a 20×26 µm pixel size on a 300×160×300mm build plate. If you're printing miniatures, jewelry, dental models, or highly detailed artistic pieces where every micron matters, the GK3 Pro is the right choice. If you need to print large parts or full batches at scale, the GK3 Ultra is built for that.
